PK SERIES

PK SERIES SELECTION CONFIGURATION

●Tool magazine

●Full closed-loop grating ruler

●Right angle milling head

●Attachment head

●Flat rotating disk

●FANUC system/or other systems

Project		Unit	ModeL
Project		Unit	PK130-A	PK130-B	PK130-C	PK160-A	PK160-B
Workbench	Workbench dimensions (L × W)	mm	1400×1600	1600×1800	1800×2200	2000×2500	2500×3000
	Maximum load of worktable	kg	8000	15000	15000	20000	20000
	T-groove (groove number-groove width × pitch)	mm	9-22×160	9-28×160	7-28×200	7-28×250	7-28×320
	Splitting angle	o	0.001	0.001	0.001	0.001	0.001
	Benchmark aperture	mm	Φ140H7	Φ140H7	Φ140H7	Φ140H7	Φ140H7
Coordinate range	Table left and right stroke (X1 axis)	mm	2500	3000	3400	3500/4000	3000/4000/6000
	Table stroke forward and backward (Y1 axis)	mm	2000	2000	2000	2000/2500	3000/4000
	Vertical headstock up and down stroke (Z1 axis)	mm	1500	1500	1500	1600	1600/2000
	Boring rod front and rear stroke (W-axis)	mm	700	700	700	900	900
	Distance from end face of horizontal spindle to center of worktable	mm	0~2000	0~2000	0~2000	0~2000/2500	0~3000/4000
	Distance from the nose end of the spindle to the center of the workbenc	mm	100~2200	200~2200	400~2200	350~2500	600~2500
Spindle	Spindle diameter	mm	φ130	φ130	φ130	φ160	φ160
	Spindle hole taper	/	BT50	BT50	BT50	BT50	BT50
	Spindle speed	rpm	10~2500	10~2500	10~2500	10~2000	10~2000
	Maximum torque of the spindle	Nm	2590	3868	3868	2553/3063/3831/4597	3063/3831/4597
	Spindle motor power	kW	22	30	30	30/37145/55	37145/55
	Number of spindle speed band	Stage	2	2	2	2	2
	Transmission mode	/	Gear transmission	Gear transmission	Gear transmission	Gear transmission	Gear transmission
Feed rate	Rapid movement speed(X/YIZW)	m/min	10/10/10/4	10/10/10/4	10/10/10/4	10/10/10/4	10/10/10/4
Feed rate	Cutting feed speed(X/YIZW)	m/min	6/6/6/2	6/6/6/2	6/6/6/2	6/6/6/2	6/6/6/2
	Cooling pump motor	kW	0.75	0.75	0.75	0.75	0.75
Precision	Positioning accuracy(X/YIZW)	mm	0.025/0.025/0.025/0.025
	Repeated positioning accuracy(X/YIZ/W)	mm	0.017/0.017/0.017/0.018
	Turntable positioning accuracy	"	10	10	10	10	10
	Turntable repeat accuracy	"	4	4	4	4	4
System	CNC system	/	SIEMENS 828D	SIEMENS 828D	SIEMENS 828D	SIEMENS 828D	SIEMENS 828D
Power source	Power supply	KVA	≥ 80	≥ 80	≥ 80	≥ 95	≥ 105
Air pressure	Air demand	kg/cm2	≥6	≥6	≥6	≥6	≥6
Air pressure	Air source flow	m3/min	≥ 0.5	≥0.5	≥ 0.5	≥0.5	≥ 0.5
	Machine weight (approx.)	kg	30000	40000	43000	55000	60000
